Juki MO-104DN
SKU
$1,099.00
Out of stock
Price inc. GST
Out of stock
Out of stock
The MO-104DN overlock sewing machine produces beautifully finished seams. With a wide range of stitch patterns, you can easily sew stretchy and knit materials. This 2/3/4 thread overlocker is equipped with fantastic features, like automatic rolled hemming and differential feed, so you can execute your projects seamlessly.
Description
Features:
- Adjustable presser foot pressure
- Adjust stitch length by simply turning dial located on the exterior right-hand side within the range 1 to 4mm
- Automatic rolled hemming
- Cutting width can be adjusted quickly for perfect seams and rolled edges
- Differential feed is easily controlled and adjusted by a dial located on the exterior right-hand side
- Easy and Efficient threading
- LED light fixture
- Lower looper threader allows for easy threading in seconds
- No wrapping, just follow the colour coded thread path
- Sewing light
- There is no need to change the throat plate or foot
- Upper looper converter option for MO-104DN
Specifications:
| Dimensions | 315(W) x 290(D) x 290(H)mm |
| Weight | 7.0kg |
| Sewing speed | Max. 1,500spm |
| 4-Thread overlock | ✓ |
| 3-Thread overlock | ✓ |
| 2-Thread overcast | Option |
| Rolled hem | ✓ |
| Narrow overlock | ✓ |
| Frill 3-thread rolled hem with diff. feed | ✓ |
| 3-thread flatlock | ✓ |
| Interlock | – |
| Chain stitch | – |
| 4-Thread cover stitch | – |
| 3-Thread cover stitch | – |
| Number of needles | 1/2 Needles |
| Needle | SCHMETZ 130/705 H Nm 70,80,90 |
| Number of threads | 2/3/4 Threads |
| Differential feed ratio | 0.7-2.0 Ratio |
| Easy threader | – |
| Lower looper threader | – |
| TWA (Tweak Width Adjustment) | – |
| Presser foot pressure adjustment | Stepless adjustment |
| Micro-lifter | – |
| Automatic rolled hemming | Automatic rolled hemming lever |
| Retractable upper knife | ✓ |
| 2-Thread converter | Option |
| Thread cutter | – |
| Adjusting cutting width | ✓ |
| Safety design | – |
| Light | LED |
| Presser foot lift (1 step/2 steps) | 5mm/7.5mm |
| Stitch length | 1-4mm |
| Stitch width | Left needle： 5-7mm Right needle： 3-5mm Rolled hem： 1.8-2.2mm |
| Magnet Needle Tray | – |
| Waste collector | Option |
| Knee Lifting Lever | – |
| Operation support | Youtube |
| Accessories | Electronic foot control Spool caps Tweezers Cleaning brush/Needle inserter Nets Looper threader Needle set 130/705 Small screwdriver Oiler Accessory bag Dust cover Instruction manual |
- Electronic foot control
- Spool caps
- Tweezers
- Cleaning brush/Needle inserter
- Nets
- Looper threader
- Needle set 130/705
- Small screwdriver
- Oiler
- Accessory bag
- Dust cover
- Instruction manual
